Designing a Resilient Distribution Grid: The Engineering Decisions That Matter Most

Resiliency Relies on Design

Resiliency is becoming the defining priority in power distribution. Utilities are managing aging infrastructure, new load pressures from EVs and electrification, more extreme weather events, and rapid DER growth. While automation and high-tech equipment often dominate the conversation, the foundation of grid resiliency is much more straightforward: it begins with good design.

Before any construction begins, thousands of engineering decisions determine how well a system will perform when reliability is on the line. Every day at Sigma, we see how core elements of distribution design—conductor selection, structural loading, switching schemes, precise field data, and rigorous QA—directly shape the strength and performance of the grid.

Below are the design decisions that matter most.

1. Conductor & Configuration Choices Set the Foundation

Conductor selection remains one of the highest-impact decisions in distribution engineering. The type, size, insulation, and configuration directly influence ampacity, voltage performance, system losses, and the system’s ability to support future growth.

Good design looks ahead at both today’s load and the next decade of EV chargers, rooftop solar, battery storage, and increasing customer density. Across many of the programs we support, we’re seeing utilities shift from ACSR to AAAC due to better sag performance and reduced losses. In many cases, even a modest increase in conductor size can delay the need for major system upgrades by several years, making it one of the most cost-effective resiliency decisions available.

2. Pole Loading & Structural Strength Drive System Resilience

Structural integrity is the backbone of a resilient grid. Pole loading analysis determines whether existing structures can support new attachments, withstand weather challenges, and maintain required safety margins.

As joint use pressures grow and storm events become more severe, many utilities are moving toward proactive pole replacement and pole-by-pole assessments. When evaluating existing networks, we frequently see loading issues on older Class 5 and Class 6 poles—particularly where multiple telecom attachers have accumulated over time. In several recent storm evaluations, failures were traced back to long-standing loading issues: aging hardware, undersized poles, and layers of attachments that were never re-analyzed after installation. Addressing these structural gaps early significantly reduces both operational risk and rework.

3. Switching & Protection Schemes Influence Outage Duration

Outage duration is influenced as much by engineering design as by operations. Reclosers, sectionalizers, automated switches, and modern protection schemes only deliver their full value when placed and coordinated correctly.

Thoughtful switching design limits fault exposure, strengthens sectionalization, and ensures automation platforms can operate as intended. Many outage investigations reveal sectionalizing gaps; there are too few switches or poorly placed devices that allow faults to affect unnecessarily large portions of the system. We also see common coordination issues between legacy reclosers and newer automation-ready devices. When spacing, device selection, and coordination settings are aligned, fault isolation improves dramatically.

4. Smart Equipment Placement Matters More Than the Device Itself

Utilities are investing heavily in sensors, automation-ready devices, and communications hardware to support visibility and automation, but the return depends heavily on where and how those devices are placed.

Equipment added without consideration for system topology or communication pathways rarely performs as intended. Strategic placement, especially at key tie points, allows operators to isolate faults faster and maintain load-transfer capability. On several programs, optimizing placement alone has reduced fault-location time by 30–40% without adding a single new device.

5. Accurate Field Data Prevents Delays, Rework, and Cost Overruns

Even the best design fails without accurate field data. Structure dimensions, clearances, vegetation conditions, joint-use attachments, and environmental constraints all shape the final engineering package.

Field inaccuracies are among the largest drivers of redesigns, permitting delays, material adjustments, and construction inefficiencies. In our experience, more than half of design rework can be traced back to incomplete or incorrect data collected in the field. To mitigate this, Sigma has standardized field collection forms, photo documentation requirements, and safety protocols so every designer receives consistent, high-quality inputs.

6. QA/QC Discipline Ensures Resiliency Is Built Into Every Package

Resiliency is achieved through the accumulation of hundreds of correct design choices, not just one. Robust QA/QC processes identify inconsistencies early, reinforce standards, and ensure alignment across large multi-year programs.

Formal 30/60/90 reviews catch variances before they reach construction and reduce downstream delays. Standardized design templates save time and significantly reduce errors, especially across programs with dozens of designers working concurrently. When every package aligns to the same structure, naming conventions, and assumptions, utilities experience fewer surprises in the field.

Building Reliability Starts Here

As utilities modernize their distribution networks, resiliency can’t be treated as a feature. It has to be engineered into the system from the beginning. That’s why Sigma’s approach to distribution design emphasizes three fundamentals:

• Accurate field data that informs every downstream decision
• Engineering discipline and standards that ensure consistency at scale
• A partnership mindset that helps utilities strengthen reliability year after year

Remember that strong grids aren’t built by accident. They’re designed with intention.



By RANDY COLEMAN, PE, Director of Engineering

Randy Coleman, PE is the Director of Engineering at Sigma Technologies, where he leads distribution engineering strategy, standards, and technical delivery across large-scale utility programs. He brings a utility-informed perspective to Sigma’s work, focusing on resilient design, disciplined engineering practices, and scalable processes that help customers strengthen reliability and modernize their distribution networks.
